Certification Conformity

FCC and ISED Certification

Component Manufacturer Model Operating Frequency (MHz) FCC ID IC ID

B-Pillar Endpoint

Tesla

1089773E

13.56

2400-2483.5

2AEIM-1089773E

20098-1089773E

Center Console Tesla 1089774

13.56

2400-2483.5

2AEIM-1089774

20098-1089774

Rear Endpoint

Tesla

1089775

2400-2483.5

2AEIM-1089775

20098-1089775

Key fob Tesla 1133148 2400-2483.5 2AEIM-1133148 20098-1133148
TPMS

Tesla

1472547G

2400-2483.5

2AEIM-1472547G

20098-1472547G

Radar Continental ARS 4-B 76000-77000 OAYARS4B 4135A-ARS4B
Homelink (if equipped) Gentex ADHL5C 286-440MHz NZLADHL5C 4112A-ADHL5C
Car PC

Manufactured approx. 2017-2019

Tesla

1098058

YZP-RBHP-B216C

RI7LE940B6NA

RBHP-B216C

5131A-LE940B6NA

Car PC

Manufactured approx. 2019-2022

Tesla

1506277

YZP-RBHP-B216C

RI7LE940B6NA

RBHP-B216C

5131A-LE940B6NA

Car PC Manufactured approx. January–July 2022 Tesla 1960100 XMR2020AG525RGL YZP-ATC5CPC001 10224A-2020AG525R 7414C-ATC5CPC001
Car PC

Manufactured approx. August 2022+

Tesla

1960100

XMR2020AG525RGL XMR202201AF51Y 10224A-2020AG525R 10224A-202201AF51Y
Wireless Charger Tesla

WC3

127.72KHz

2AEIM-WC3

20098-WC3

The devices listed above comply with Part 15 of the FCC rules and Industry Canada's license-exempt RSS Standard(s) and EU Directive 2014/53/EU.

Operation is subject to the following two conditions:
  1. This device may not cause harmful interference; and
  2. This device must accept any interference received, including interference that may cause undesired operation.

Changes or modifications not expressly approved by Tesla could void your authority to operate the equipment.

Radio Frequency Information

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, try to correct the interference by one or more of the following measures:
  • Reorient or relocate the receiving antenna.
  • Increase the separation between the equipment and receiver.
  • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
  • Consult the dealer or an experienced radio/TV technician to help.
Warning IconA warning icon, calling your attention to a possibly risky situation
CAUTION
This equipment and its antennas must not be co-located or operated with another antenna or transmitter.

Radiation Exposure Statement

The products comply with the FCC/ISED RF Exposure for Low Power Consumer Wireless Power Transfer. RF exposure limits are set forth for an uncontrolled environment and are safe for intended operation as described in this manual. The farthest RF exposure demonstrated by compliance was at 20cm and farther from the user's body; set the device to low output power if such function is available.

Device Approval - Taiwan

Key Fob:

Image of example of approval label.

TPMS:

Image of example of approval label.
Image of example of approval label.
Image of example of approval label.

For 2.4G and 5G Devices

減少電磁波影響,請妥適使用 無線資訊傳輸設備避免影響附近雷達系統之操作 低功率電波輻射性電機管理辦法 第十二條經型式認證合格之低功率射頻電機,非經許可,公司、商號或使 用者均不得擅自變更頻率、加大功率或變更原設計之特性及功能。 第十四條低功率射頻電機之使用不得影響飛航安全及干擾合法通信;經發 現有干擾現象時,應立即停用,並改善至無干擾時方得繼續使用。 前項合法通信,指依電信規定作業之無線電信。低功率射頻電機須忍受合法通信 或工業、科學及醫療用電波輻射性電機設備之干擾 在5.25-5.35 秭赫頻帶內操作之無線資訊傳輸設備,限於室內使用。

Image of example of label.

產 品名稱:無線手機充電器 Wireless Phone Charger

產 品型號: WC3

最大輸出:DC 5 V 15 W x 2

輸入: DC 13.5 V , 4 A

台灣特斯拉汽車有限公司

臺北市內湖區民權東路6段11巷6號

操作溫度: -40 ℃~55 ℃

Image of example of label.
